The disassembly of the bearing is carried out on a regular basis and when the bearing is replaced. After disassembly, if you continue to use it, or when you need to check the condition of the bearing, the disassembly should be carried out as carefully as the installation. Pay attention not to damage the parts of the bearing, especially the disassembly of the interference fit bearing, which is difficult to operate.
It is also very important to design and manufacture disassembly tools according to needs. When disassembling, study the disassembly method and sequence according to the drawings, and investigate the matching conditions of the bearing to ensure that the disassembly operation is foolproof.
Disassembly of the outer ring For the outer ring with interference fit, a few screws for extruding the outer ring are set on the circumference of the shell in advance, and the screws are tightened evenly while being removed. These screw holes are usually covered with blind plugs and separable bearings such as tapered roller bearings. Several cuts are provided on the housing blocking shoulders. Use spacers to remove them with a press or gently tap them.
The disassembly of the inner ring can be the easiest to pull out with a press. At this time, pay attention to let the inner ring bear its pulling force. Furthermore, the pull-out clamps shown are mostly used, and no matter what kind of clamps, they must be firmly clamped to the side of the inner ring. For this reason, it is necessary to consider the size of the shoulder of the shaft, or study the processing of the upper groove at the shoulder in order to use the drawing fixture.
The inner ring of large bearings is disassembled by hydraulic method. Oil pressure is applied through the oil hole provided in the bearing to make it easy to draw. For bearings with a large width, the hydraulic method and the drawing fixture are used together for disassembly.
The inner ring of cylindrical roller bearing can be removed by induction heating method. The method of drawing after heating the part in a short time to expand the inner ring. Where a large number of these bearing inner rings need to be installed, induction heating is also used.
When disassembling the bearing for inspection, first make a record of the appearance with photography or other methods. In addition, confirm the amount of remaining lubricant and sample the lubricant before cleaning the bearing.
a. The cleaning of the bearing is divided into rough washing and fine washing, and a metal mesh rack can be placed on the bottom of the used container.
b. When rough washing, use a brush in oil to remove grease or adhesions. If you rotate the bearing in oil at this time, be careful that the rolling surface may be damaged by foreign matter.
c. When fine washing, slowly rotate the bearing in oil, and must be carried out carefully.
Commonly used cleaning agents are neutral water-free diesel or kerosene, and sometimes warm lye etc. are used as needed. No matter which cleaning agent is used, it must be filtered frequently to keep it clean.
After cleaning, immediately apply anti-rust oil or anti-rust grease on the bearing.
