Whether the bearing is installed correctly affects accu […]
Whether the bearing is installed correctly affects accuracy, life and performance. Therefore, the design and assembly department must fully study the bearing installation. Hope to install in accordance with operating standards. The work standard items are usually as follows:
(1) Clean the bearing and its related parts
(2) Check the size and finishing of related parts
(4) Inspection after bearing installation
(5) Supply lubricant
It is hoped that the bearing package will be opened just before installation. General grease lubrication, do not clean, directly filled with grease. Lubricating oil does not need to be cleaned in general. However, the bearings for instruments or high-speed use should be cleaned with clean oil to remove the anti-rust agent coated on the bearings. Bearings with anti-rust agent removed are easy to rust, so they cannot be left alone. In addition, bearings that have been packed with grease can be used directly without cleaning.
The installation method of the bearing varies with the bearing structure, fit and conditions. Generally, since most of the shaft rotates, the inner ring needs an interference fit. Bearings with cylindrical bores are usually pressed in with a press or hot-fitting method. In the case of a tapered hole, install it directly on the tapered shaft or use a sleeve.
When it is installed to the shell, there is generally a lot of clearance fit, and the outer ring has an interference. It is usually pressed in with a press, or there is a shrink fit method for installation after cooling. When dry ice is used as the coolant, the moisture in the air will condense on the surface of the bearing when the shrink fit is installed. Therefore, appropriate anti-rust measures are required.
